CLEVELAND CABLE NYM-J 3 × 2.5 mm² PVC wiring cable, rated 300/500V, comprising three 2.5 mm² solid copper Class 1 conductors with 1 × 1.78 mm construction, individually insulated with PVC and laid together with an extruded thermoplastic filler and grey PVC outer sheath. The cable has Brown, Blue and Green/Yellow core identification, an approximate weight of 165 kg/km and is suitable for fixed domestic, commercial and industrial electrical installations in dry, moist or wet areas, including installation under plaster and in concrete. The cable complies with applicable BS EN/IEC standards.
| Cable Type | NYM-J |
| No. of Cores | 3 Core |
| Conductor Size | 2.5 mm² per core |
| Conductor | Solid Copper, Class 1 |
| Conductor Stranding | 1 × 1.78 mm |
| Insulation | PVC |
| Sheath Colour | Grey |
| Voltage Rating | 300/500 V |
| Core Identification | Brown / Blue / Green-Yellow |
| Standard | BS EN 50265-2-1, VDE 0295, IEC 60332-1-2, IEC 60228 |
| Application | Domestic, commercial & industrial fixed wiring |
